General Specifications
Power Supply: 100 – 240V AC, ~ 50/60Hz
Operating Temperature: 0°C – 45°C
Country of Origin: China
Audio Specifications
Total Speaker Power Output (Max. @THD 1%): 110W
Soundbar Output Power: 2 × 27W
Subwoofer Output Power: 56W
Soundbar Transducer: 2 × 2" full-range drivers
Subwoofer Transducer: 4" wired subwoofer
Max SPL: 82dB
Frequency Response: 40Hz – 20kHz
Audio Inputs: 1 Optical, Bluetooth (USB is for service only)
Dimensions & Weight
Soundbar (W × H × D): 900 × 67 × 63 mm / 35.4" × 2.6" × 2.5"
Subwoofer (W × H × D): 150 × 320 × 220 mm / 6" × 12.6" × 8.7"
Soundbar Weight: 1.5 kg
Subwoofer Weight: 2.8 kg
Control & Connection Specifications
Bluetooth Version: 4.2
Bluetooth Profiles: A2DP V1.3, AVRCP V1.5
Bluetooth Frequency Range: 2402 – 2480 MHz
Bluetooth Max. Transmitting Power: < 0 dBm (EIRP)
Modulation Type: GFSK, π/4 DQPSK
Video Specifications
HDMI Video Output (with ARC): 1
HDMI HDCP Version: 1.4
|
